Public functions. More...

Collaboration diagram for PublicMemberFunctions:

Functions
PUBLIC_API STATUS	createPeerConnection (PRtcConfiguration, PRtcPeerConnection *)
	Initialize a RtcPeerConnection with the provided Configuration. More...

PUBLIC_API STATUS	addConfigToServerList (PRtcPeerConnection *, PIceConfigInfo)
	Give peer connection an ice config to add to its server list. More...

PUBLIC_API STATUS	freePeerConnection (PRtcPeerConnection *)
	Free a RtcPeerConnection. More...

PUBLIC_API STATUS	peerConnectionOnIceCandidate (PRtcPeerConnection, UINT64, RtcOnIceCandidate)
	Set a callback when new Ice collects new local candidate. More...

PUBLIC_API STATUS	peerConnectionOnSenderBandwidthEstimation (PRtcPeerConnection, UINT64, RtcOnSenderBandwidthEstimation)
	Set a callback for transport-wide sender bandwidth estimation results. More...

PUBLIC_API STATUS	peerConnectionOnDataChannel (PRtcPeerConnection, UINT64, RtcOnDataChannel)

PUBLIC_API STATUS	peerConnectionOnConnectionStateChange (PRtcPeerConnection, UINT64, RtcOnConnectionStateChange)

PUBLIC_API STATUS	peerConnectionGetLocalDescription (PRtcPeerConnection, PRtcSessionDescriptionInit)

PUBLIC_API STATUS	peerConnectionGetCurrentLocalDescription (PRtcPeerConnection, PRtcSessionDescriptionInit)

PUBLIC_API STATUS	peerConnectionAsync (startRoutine fn, PVOID data)

PUBLIC_API STATUS	createOffer (PRtcPeerConnection, PRtcSessionDescriptionInit)
	Populate the provided answer that contains an RFC 3264 offer with the supported configurations for the session. More...

PUBLIC_API NullableBool	canTrickleIceCandidates (PRtcPeerConnection)
	The canTrickleIceCandidates attribute indicates whether the remote peer is able to accept trickled ICE candidates. The value is determined based on whether a remote description indicates support for trickle ICE. Prior to the completion of setRemoteDescription, this value is null. More...

PUBLIC_API STATUS	createAnswer (PRtcPeerConnection, PRtcSessionDescriptionInit)
	Populate the provided answer that contains an RFC 3264 answer with the supported configurations for the session. More...

PUBLIC_API STATUS	serializeSessionDescriptionInit (PRtcSessionDescriptionInit, PCHAR, PUINT32)
	Create a JSON string from RtcSessionDescriptionInit. More...

PUBLIC_API STATUS	deserializeSessionDescriptionInit (PCHAR, UINT32, PRtcSessionDescriptionInit)
	Parses a JSON string and returns an allocated PSessionDescriptionInit. More...

PUBLIC_API STATUS	deserializeRtcIceCandidateInit (PCHAR, UINT32, PRtcIceCandidateInit)
	Parses a JSON string and populates a PRtcIceCandidateInit. More...

PUBLIC_API STATUS	setLocalDescription (PRtcPeerConnection, PRtcSessionDescriptionInit)
	Instructs the RtcPeerConnection to apply the supplied RtcSessionDescriptionInit as the local description. More...

PUBLIC_API STATUS	setRemoteDescription (PRtcPeerConnection, PRtcSessionDescriptionInit)
	Instructs the RtcPeerConnection to apply the supplied RtcSessionDescriptionInit as the remote description. More...

PUBLIC_API STATUS	restartIce (PRtcPeerConnection)
	Instructs the RtcPeerConnection that ICE should be restarted. Subsequent calls to createOffer will create descriptions to restart ICE. More...

PUBLIC_API STATUS	closePeerConnection (PRtcPeerConnection)
	Close the underlying DTLS session and IceAgent connection. Trigger RtcOnConnectionStateChange to RTC_PEER_CONNECTION_STATE_CLOSED. More...

PUBLIC_API STATUS	addTransceiver (PRtcPeerConnection, PRtcMediaStreamTrack, PRtcRtpTransceiverInit, PRtcRtpTransceiver *)
	Create a new RtcRtpTransceiver and add it to the set of transceivers. More...

PUBLIC_API STATUS	transceiverOnFrame (PRtcRtpTransceiver, UINT64, RtcOnFrame)
	Set a callback for transceiver frame. More...

PUBLIC_API STATUS	transceiverOnBandwidthEstimation (PRtcRtpTransceiver, UINT64, RtcOnBandwidthEstimation)
	Set a callback for bandwidth estimation results. More...

PUBLIC_API STATUS	transceiverOnPictureLoss (PRtcRtpTransceiver, UINT64, RtcOnPictureLoss)
	Set a callback for picture loss packet (PLI) More...

PUBLIC_API STATUS	freeTransceiver (PRtcRtpTransceiver *)
	Frees the previously created transceiver object. More...

PUBLIC_API STATUS	initKvsWebRtc (VOID)
	Initializes global state needed for all RtcPeerConnections. It must only be called once. More...

PUBLIC_API STATUS	deinitKvsWebRtc (VOID)
	Deinitializes global state needed for all RtcPeerConnections. It must only be called once. More...

PUBLIC_API STATUS	addSupportedCodec (PRtcPeerConnection, RTC_CODEC)
	Adds to the list of codecs we support receiving. More...

PUBLIC_API STATUS	writeFrame (PRtcRtpTransceiver, PFrame)
	Packetizes and sends media via the configuration specified by the RtcRtpTransceiver. More...

PUBLIC_API STATUS	updateEncoderStats (PRtcRtpTransceiver, PRtcEncoderStats)
	call this function to update stats which depend on external encoder More...

PUBLIC_API STATUS	addIceCandidate (PRtcPeerConnection, PCHAR)
	Provides a remote candidate to the ICE Agent. More...

PUBLIC_API STATUS	createDataChannel (PRtcPeerConnection, PCHAR, PRtcDataChannelInit, PRtcDataChannel *)
	createDataChannel creates a new RtcDataChannel object with the given label. More...

PUBLIC_API STATUS	dataChannelOnMessage (PRtcDataChannel, UINT64, RtcOnMessage)
	Set a callback for data channel message. More...

PUBLIC_API STATUS	dataChannelOnOpen (PRtcDataChannel, UINT64, RtcOnOpen)
	Set a callback for data channel open. More...

PUBLIC_API STATUS	dataChannelSend (PRtcDataChannel, BOOL, PBYTE, UINT32)
	Send data via the PRtcDataChannel. More...

PUBLIC_API STATUS	discoverNatBehavior (PCHAR, NAT_BEHAVIOR , NAT_BEHAVIOR , IceSetInterfaceFilterFunc, UINT64)
	Use the process described in https://tools.ietf.org/html/rfc5780#section-4.3 to discover NAT behavior. More...

PUBLIC_API PCHAR	getNatBehaviorStr (NAT_BEHAVIOR natBehavior)
	Return the string representation for each NAT_BEHAVIOR enum. More...

PUBLIC_API STATUS	createSignalingClientSync (PSignalingClientInfo, PChannelInfo, PSignalingClientCallbacks, PAwsCredentialProvider, PSIGNALING_CLIENT_HANDLE)
	Creates a Signaling client and returns a handle to it. More...

PUBLIC_API STATUS	freeSignalingClient (PSIGNALING_CLIENT_HANDLE)
	Frees the Signaling client object. More...

PUBLIC_API STATUS	signalingClientSendMessageSync (SIGNALING_CLIENT_HANDLE, PSignalingMessage)
	Send a message through a Signaling client. More...

PUBLIC_API STATUS	signalingClientGetIceConfigInfoCount (SIGNALING_CLIENT_HANDLE, PUINT32)
	Gets the retrieved ICE configuration information object count. More...

PUBLIC_API STATUS	signalingClientGetIceConfigInfo (SIGNALING_CLIENT_HANDLE, UINT32, PIceConfigInfo *)
	Gets the ICE configuration information object given its index. More...

PUBLIC_API STATUS	signalingClientFetchSync (SIGNALING_CLIENT_HANDLE)
	Fetches all assets needed to ready the state machine before attempting to connect. Can also be used to reallocate missing / expired assets before reconnecting. More...

PUBLIC_API STATUS	signalingClientConnectSync (SIGNALING_CLIENT_HANDLE)
	Connects the signaling client to the web socket in order to send/receive messages. More...

PUBLIC_API STATUS	signalingClientDisconnectSync (SIGNALING_CLIENT_HANDLE)
	Disconnects the signaling client. More...

PUBLIC_API STATUS	signalingClientGetCurrentState (SIGNALING_CLIENT_HANDLE, PSIGNALING_CLIENT_STATE)
	Gets the Signaling client current state. More...

PUBLIC_API STATUS	signalingClientGetStateString (SIGNALING_CLIENT_STATE, PCHAR *)

PUBLIC_API STATUS	signalingClientDeleteSync (SIGNALING_CLIENT_HANDLE)
	Deletes the signaling channel referenced by SIGNALING_CLIENT_HANDLE. More...

PUBLIC_API STATUS	signalingClientGetMetrics (SIGNALING_CLIENT_HANDLE, PSignalingClientMetrics)
	Get signaling related metrics. More...

PUBLIC_API STATUS	peerConnectionGetMetrics (PRtcPeerConnection, PPeerConnectionMetrics)
	Get peer connection related metrics. More...

PUBLIC_API STATUS	iceAgentGetMetrics (PRtcPeerConnection, PKvsIceAgentMetrics)
	Get peer connection related metrics. More...

PUBLIC_API STATUS	rtcPeerConnectionGetMetrics (PRtcPeerConnection, PRtcRtpTransceiver, PRtcStats)
	Get the relevant/all metrics based on the RTCStatsType field. This does not include any signaling related metrics. The caller of the API is expected to populate requestedTypeOfStats member of PRtcStats object with one of the values in RTC_STATS_TYPE. More...

PUBLIC_API STATUS	createRtcCertificate (PRtcCertificate *)
	Creates an RtcCertificate object. More...

PUBLIC_API STATUS	freeRtcCertificate (PRtcCertificate)
	Frees previously generated RtcCertificate object. More...

Detailed Description

Public functions.

Function Documentation

◆ addConfigToServerList()

PUBLIC_API STATUS addConfigToServerList	(	PRtcPeerConnection *	ppPeerConnection,
		PIceConfigInfo	pIceConfigInfo
	)

Give peer connection an ice config to add to its server list.

Parameters

[in]	PRtcPeerConnection*	initialized RtcPeerConnection
[in]	PIceConfigInfo	Ice config info to add to this peer connection

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ addIceCandidate()

PUBLIC_API STATUS addIceCandidate	(	PRtcPeerConnection	pPeerConnection,
		PCHAR	pIceCandidate
	)

Provides a remote candidate to the ICE Agent.

This method can also be used to indicate the end of remote candidates when called with an empty string for the candidate member.

Reference: https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-addicecandidate

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in]	PCHAR	New remote ICE candidate to add

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ addSupportedCodec()

PUBLIC_API STATUS addSupportedCodec	(	PRtcPeerConnection	pPeerConnection,
		RTC_CODEC	rtcCodec
	)

Adds to the list of codecs we support receiving.

NOTE: The remote MUST only send codecs we declare

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in]	RTC_CODEC	Codec that we support receiving.

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ addTransceiver()

PUBLIC_API STATUS addTransceiver	(	PRtcPeerConnection	pPeerConnection,
		PRtcMediaStreamTrack	pRtcMediaStreamTrack,
		PRtcRtpTransceiverInit	pRtcRtpTransceiverInit,
		PRtcRtpTransceiver *	ppRtcRtpTransceiver
	)

Create a new RtcRtpTransceiver and add it to the set of transceivers.

Reference https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-addtransceiver

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in]	PRtcMediaStreamTrack	Stream track information for the codec appropriate codec, or NULL for RECVONLY
[in]	PRtcRtpTransceiverInit	PRtcRtpTransceiverInit that may configure our new Transceiver
[in,out]	PRtcRtpTransceiver*	IN/Initialized and configured RtcRtpTransceiver

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ canTrickleIceCandidates()

PUBLIC_API NullableBool canTrickleIceCandidates ( PRtcPeerConnection pPeerConnection )

The canTrickleIceCandidates attribute indicates whether the remote peer is able to accept trickled ICE candidates. The value is determined based on whether a remote description indicates support for trickle ICE. Prior to the completion of setRemoteDescription, this value is null.

Reference: https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-cantrickleicecandidates

Parameters

[in] PRtcPeerConnection Initialized RtcPeerConnection

Returns: NullableBool if not null, indicate whether remote support trickle ICE.

◆ closePeerConnection()

PUBLIC_API STATUS closePeerConnection ( PRtcPeerConnection pPeerConnection )

Close the underlying DTLS session and IceAgent connection. Trigger RtcOnConnectionStateChange to RTC_PEER_CONNECTION_STATE_CLOSED.

Reference: https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-close

Parameters

[in] PRtcPeerConnection Initialized RtcPeerConnection

Returns: - STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ createAnswer()

PUBLIC_API STATUS createAnswer	(	PRtcPeerConnection	pPeerConnection,
		PRtcSessionDescriptionInit	pSessionDescriptionInit
	)

Populate the provided answer that contains an RFC 3264 answer with the supported configurations for the session.

Reference: https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-createanswer

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in,out]	PRtcSessionDescriptionInit	IN/answer that describes the supported configurations of the RtcPeerConnection

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ createDataChannel()

PUBLIC_API STATUS createDataChannel	(	PRtcPeerConnection	pPeerConnection,
		PCHAR	pDataChannelName,
		PRtcDataChannelInit	pRtcDataChannelInit,
		PRtcDataChannel *	ppRtcDataChannel
	)

createDataChannel creates a new RtcDataChannel object with the given label.

NOTE: The RtcDataChannelInit dictionary can be used to configure properties of the underlying channel such as data reliability. NOTE: Data channel can be created only after signaling for now

Reference: https://www.w3.org/TR/webrtc/#methods-11

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in]	PCHAR	Data channel Name
[in]	PRtcDataChannelInit	Allowed to be NULL/defines underlying channel properties
[out]	PRtcDataChannel*	Created data channel with supplied channel name

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ createOffer()

PUBLIC_API STATUS createOffer	(	PRtcPeerConnection	pPeerConnection,
		PRtcSessionDescriptionInit	pSessionDescriptionInit
	)

Populate the provided answer that contains an RFC 3264 offer with the supported configurations for the session.

Reference: https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-createoffer

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in,out]	PRtcSessionDescriptionInit	IN/answer that describes the supported configurations of the RtcPeerConnection

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ createPeerConnection()

PUBLIC_API STATUS createPeerConnection	(	PRtcConfiguration	pConfiguration,
		PRtcPeerConnection *	ppPeerConnection
	)

Initialize a RtcPeerConnection with the provided Configuration.

Reference: https://www.w3.org/TR/webrtc/#constructor

Parameters

[in]	PConfiguration	Configuration to initialize provided RtcPeerConnection
[in,out]	PRtcPeerConnection	Uninitialized RtcPeerConnection

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ createRtcCertificate()

PUBLIC_API STATUS createRtcCertificate ( PRtcCertificate * ppRtcCertificate )

Creates an RtcCertificate object.

Parameters

[in,out] RtcCertificate object that will be generated and returned.

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ createSignalingClientSync()

PUBLIC_API STATUS createSignalingClientSync	(	PSignalingClientInfo	pClientInfo,
		PChannelInfo	pChannelInfo,
		PSignalingClientCallbacks	pCallbacks,
		PAwsCredentialProvider	pCredentialProvider,
		PSIGNALING_CLIENT_HANDLE	pSignalingHandle
	)

Creates a Signaling client and returns a handle to it.

Parameters

[in]	PSignalingClientInfo	Signaling client info
[in]	PChannelInfo	Signaling channel info to use/create a channel
[in]	PSignalingClientCallbacks	Signaling callbacks for event notifications
[in]	PAwsCredentialProvider	Credential provider for auth integration
[out]	PSIGNALING_CLIENT_HANDLE	Returned signaling client handle

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ dataChannelOnMessage()

PUBLIC_API STATUS dataChannelOnMessage	(	PRtcDataChannel	pRtcDataChannel,
		UINT64	customData,
		RtcOnMessage	rtcOnMessage
	)

Set a callback for data channel message.

Parameters

[in]	PRtcDataChannel	Data channel struct created by createDataChannel()
[in]	UINT64	User customData that will be passed along when RtcOnMessage is called
[in]	RtcOnMessage	User RtcOnMessage callback

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ dataChannelOnOpen()

PUBLIC_API STATUS dataChannelOnOpen	(	PRtcDataChannel	pRtcDataChannel,
		UINT64	customData,
		RtcOnOpen	rtcOnOpen
	)

Set a callback for data channel open.

Parameters

[in]	PRtcDataChannel	Data channel struct created by createDataChannel()
[in]	UINT64	User customData that will be passed along when RtcOnOpen is called
[in]	RtcOnOpen	User RtcOnOpen callback

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ dataChannelSend()

PUBLIC_API STATUS dataChannelSend	(	PRtcDataChannel	pRtcDataChannel,
		BOOL	isBinary,
		PBYTE	pMessage,
		UINT32	pMessageLen
	)

Send data via the PRtcDataChannel.

Reference: https://www.w3.org/TR/webrtc/#dfn-send

Parameters

[in]	PRtcDataChannel	Configured and connected PRtcDataChannel
[in]	BOOL	Is message binary, if false will be delivered as a string
[in]	PBYTE	Data that you wish to send
[in]	UINT32	Length of the PBYTE you wish to send

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ deinitKvsWebRtc()

PUBLIC_API STATUS deinitKvsWebRtc ( VOID )

Deinitializes global state needed for all RtcPeerConnections. It must only be called once.

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ deserializeRtcIceCandidateInit()

PUBLIC_API STATUS deserializeRtcIceCandidateInit	(	PCHAR	pJson,
		UINT32	jsonLen,
		PRtcIceCandidateInit	pRtcIceCandidateInit
	)

Parses a JSON string and populates a PRtcIceCandidateInit.

Parameters

[in]	PCHAR	JSON String of a PRtcIceCandidateInit
[in]	UINT32	Length of JSON String
[out]	PRtcIceCandidateInit	PRtcIceCandidateInit populated from JSON String

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ deserializeSessionDescriptionInit()

PUBLIC_API STATUS deserializeSessionDescriptionInit	(	PCHAR	sessionDescriptionJSON,
		UINT32	sessionDescriptionJSONLen,
		PRtcSessionDescriptionInit	pSessionDescriptionInit
	)

Parses a JSON string and returns an allocated PSessionDescriptionInit.

Parameters

[in]	PCHAR	JSON String of a RtcSessionDescriptionInit
[in]	UINT32	Length of JSON String
[out]	PRtcSessionDescriptionInit	RtcSessionDescriptionInit populated from JSON String

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ discoverNatBehavior()

PUBLIC_API STATUS discoverNatBehavior	(	PCHAR	stunServer,
		NAT_BEHAVIOR *	pNatMappingBehavior,
		NAT_BEHAVIOR *	pNatFilteringBehavior,
		IceSetInterfaceFilterFunc	filterFunc,
		UINT64	filterFuncCustomData
	)

Use the process described in https://tools.ietf.org/html/rfc5780#section-4.3 to discover NAT behavior.

Parameters

[in]	PCHAR	STUN hostname. Need to in form of stun:hostname:port
[out]	NAT_BEHAVIOR*	detected NAT mapping behavior
[out]	NAT_BEHAVIOR*	detected NAT filtering behavior
[in]	IceSetInterfaceFilterFunc	filter function for selecting local network interface to create socket. Optional.
[in]	UINT64	User data for filter function

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ freePeerConnection()

PUBLIC_API STATUS freePeerConnection ( PRtcPeerConnection * ppPeerConnection )

Free a RtcPeerConnection.

Parameters

[in] PRtcPeerConnection* RtcPeerConnection that is to be freed

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

Here is the caller graph for this function:

◆ freeRtcCertificate()

PUBLIC_API STATUS freeRtcCertificate ( PRtcCertificate pRtcCertificate )

Frees previously generated RtcCertificate object.

Parameters

[in,out] RtcCertificate object that will be freed if not NULL.

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the caller graph for this function:

◆ freeSignalingClient()

PUBLIC_API STATUS freeSignalingClient ( PSIGNALING_CLIENT_HANDLE pSignalingHandle )

Frees the Signaling client object.

NOTE: The call is idempotent.

Parameters

[in,out/opt] PSIGNALING_CLIENT_HANDLE Signaling client handle to free

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ freeTransceiver()

PUBLIC_API STATUS freeTransceiver ( PRtcRtpTransceiver * pRtcRtpTransceiver )

Frees the previously created transceiver object.

This method is currently a no-op as Transceivers are freed when freePeerConnection is called in the future when renegotiation is supported this will be useful to remove Transceivers at anytime

Parameters

[in,out/opt] PRtcRtpTransceiver* in,out/OPT RtcRtpTransceiver to be freed

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ getNatBehaviorStr()

PUBLIC_API PCHAR getNatBehaviorStr ( NAT_BEHAVIOR natBehavior )

Return the string representation for each NAT_BEHAVIOR enum.

Parameters

[in] natBehavior the NAT_BEHAVIOR enum

Returns: PCHAR string representation for the NAT_BEHAVIOR enum

◆ iceAgentGetMetrics()

PUBLIC_API STATUS iceAgentGetMetrics	(	PRtcPeerConnection	pPeerConnection,
		PKvsIceAgentMetrics	pKvsIceAgentMetrics
	)

Get peer connection related metrics.

Parameters

[in]	PRtcPeerConnection	Peer connection object
[in,out]	PKvsIceAgentMetrics	KVS ICE agent stats object

Here is the call graph for this function:

◆ initKvsWebRtc()

PUBLIC_API STATUS initKvsWebRtc ( VOID )

Initializes global state needed for all RtcPeerConnections. It must only be called once.

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ peerConnectionAsync()

PUBLIC_API STATUS peerConnectionAsync	(	startRoutine	fn,
		PVOID	data
	)

Allows use of internal threadpool

Parameters

[in]	startRoutine	function pointer to execute in threadpool
[in]	PVOID	void pointer to pass to function pointer

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ peerConnectionGetCurrentLocalDescription()

PUBLIC_API STATUS peerConnectionGetCurrentLocalDescription	(	PRtcPeerConnection	pRtcPeerConnection,
		PRtcSessionDescriptionInit	pRtcSessionDescriptionInit
	)

Load the sdp field of PRtcSessionDescriptionInit with current local session description

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in,out]	PRtcSessionDescriptionInit	IN/PRtcSessionDescriptionInit whose sdp field will be modified.

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

Here is the caller graph for this function:

◆ peerConnectionGetLocalDescription()

PUBLIC_API STATUS peerConnectionGetLocalDescription	(	PRtcPeerConnection	pRtcPeerConnection,
		PRtcSessionDescriptionInit	pRtcSessionDescriptionInit
	)

Load the sdp field of PRtcSessionDescriptionInit with pending or current local session description

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in,out]	PRtcSessionDescriptionInit	IN/PRtcSessionDescriptionInit whose sdp field will be modified.

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ peerConnectionGetMetrics()

PUBLIC_API STATUS peerConnectionGetMetrics	(	PRtcPeerConnection	pPeerConnection,
		PPeerConnectionMetrics	pPeerConnectionMetrics
	)

Get peer connection related metrics.

Parameters

[in]	PRtcPeerConnection	Peer connection object
[in,out]	PPeerConnectionMetrics	Peer connection stats object

Here is the call graph for this function:

◆ peerConnectionOnConnectionStateChange()

PUBLIC_API STATUS peerConnectionOnConnectionStateChange	(	PRtcPeerConnection	pRtcPeerConnection,
		UINT64	customData,
		RtcOnConnectionStateChange	rtcOnConnectionStateChange
	)

Set a callback for connection state change

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in]	UINT64	User customData that will be passed along when RtcOnDataChannel is called
[in]	RtcOnIceCandidate	User RtcOnConnectionStateChange callback

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ peerConnectionOnDataChannel()

PUBLIC_API STATUS peerConnectionOnDataChannel	(	PRtcPeerConnection	pRtcPeerConnection,
		UINT64	customData,
		RtcOnDataChannel	rtcOnDataChannel
	)

Set a callback for data channel

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in]	UINT64	User customData that will be passed along when RtcOnDataChannel is called
[in]	RtcOnDataChannel	User RtcOnDataChannel callback

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ peerConnectionOnIceCandidate()

PUBLIC_API STATUS peerConnectionOnIceCandidate	(	PRtcPeerConnection	pRtcPeerConnection,
		UINT64	customData,
		RtcOnIceCandidate	rtcOnIceCandidate
	)

Set a callback when new Ice collects new local candidate.

NOTE: When IceAgent is done with collecting candidates, RtcOnIceCandidate will be called with NULL.

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in]	UINT64	User customData that will be passed along when RtcOnIceCandidate is called
[in]	RtcOnIceCandidate	User callback when new local candidate is found

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ peerConnectionOnSenderBandwidthEstimation()

PUBLIC_API STATUS peerConnectionOnSenderBandwidthEstimation	(	PRtcPeerConnection	pRtcPeerConnection,
		UINT64	customData,
		RtcOnSenderBandwidthEstimation	rtcOnSenderBandwidthEstimation
	)

Set a callback for transport-wide sender bandwidth estimation results.

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in]	UINT64	User customData that will be passed along when RtcOnSenderBandwidthEstimation is called
[in]	RtcOnSenderBandwidthEstimation	User RtcOnSenderBandwidthEstimation callback

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ restartIce()

PUBLIC_API STATUS restartIce ( PRtcPeerConnection pPeerConnection )

Instructs the RtcPeerConnection that ICE should be restarted. Subsequent calls to createOffer will create descriptions to restart ICE.

Reference: https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-restartice

Parameters

[in] PRtcPeerConnection Initialized RtcPeerConnection

Returns: - STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ rtcPeerConnectionGetMetrics()

PUBLIC_API STATUS rtcPeerConnectionGetMetrics	(	PRtcPeerConnection	pRtcPeerConnection,
		PRtcRtpTransceiver	pRtcRtpTransceiver,
		PRtcStats	pRtcMetrics
	)

Get the relevant/all metrics based on the RTCStatsType field. This does not include any signaling related metrics. The caller of the API is expected to populate requestedTypeOfStats member of PRtcStats object with one of the values in RTC_STATS_TYPE.

Stats specific expectations: IceServerStats: This return stats for a specific ICE server. In a multi server configuration, it is upto to the application to get Stats for every server being supported / desired server. The application is expected to pass in the specific iceServerIndex for which the stats are desired

Parameters

[in]	PRtcPeerConnection	Peer connection for which the stats need to be collected
[in]	PRtcRtpTransceiver	set to desired transceiver for RTP stats, NULL otherwise If set to NULL for RTP stats, the stats for the first transceiver are returned.
[in,out]	PRtcStats	The stats object with the RTCStatsType field populated

Reference: https://www.w3.org/TR/webrtc/#rtcpeerconnection-interface-extensions-1

Here is the call graph for this function:

◆ serializeSessionDescriptionInit()

PUBLIC_API STATUS serializeSessionDescriptionInit	(	PRtcSessionDescriptionInit	pSessionDescriptionInit,
		PCHAR	sessionDescriptionJSON,
		PUINT32	sessionDescriptionJSONLen
	)

Create a JSON string from RtcSessionDescriptionInit.

Parameters

[in]	PRtcSessionDescriptionInit	Source RtcSessionDescriptionInit that will become JSON string
[out]	PCHAR	JSON string generated from PRtcSessionDescriptionInit
[out]	PUINT32	If PCHAR is null this is the required buffer size. If PCHAR is non-NULL this is the length of the output

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ setLocalDescription()

PUBLIC_API STATUS setLocalDescription	(	PRtcPeerConnection	pPeerConnection,
		PRtcSessionDescriptionInit	pSessionDescriptionInit
	)

Instructs the RtcPeerConnection to apply the supplied RtcSessionDescriptionInit as the local description.

Reference: https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-setlocaldescription

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in,out]

Here is the call graph for this function:

◆ setRemoteDescription()

PUBLIC_API STATUS setRemoteDescription	(	PRtcPeerConnection	pPeerConnection,
		PRtcSessionDescriptionInit	pSessionDescriptionInit
	)

Instructs the RtcPeerConnection to apply the supplied RtcSessionDescriptionInit as the remote description.

Reference: https://www.w3.org/TR/webrtc/#dom-rtcpeerconnection-setremotedescription

Parameters

[in]	PRtcPeerConnection	Initialized RtcPeerConnection
[in,out]	PRtcSessionDescriptionInit	IN/RtcSessionDescriptionInit that becomes our new remote description

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ signalingClientConnectSync()

PUBLIC_API STATUS signalingClientConnectSync ( SIGNALING_CLIENT_HANDLE signalingClientHandle )

Connects the signaling client to the web socket in order to send/receive messages.

NOTE: The call will succeed only when the signaling client is in a ready state.

Parameters

[in] SIGNALING_CLIENT_HANDLE Signaling client handle

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ signalingClientDeleteSync()

PUBLIC_API STATUS signalingClientDeleteSync ( SIGNALING_CLIENT_HANDLE signalingClientHandle )

Deletes the signaling channel referenced by SIGNALING_CLIENT_HANDLE.

NOTE: The function is intended to be used to clean up the backend resources and as such should be called at the end of the lifecycle of the signaling channel resource. Attempting to connect to the channel or send a message will result in an error or an unpredictable results after this call.

NOTE: The call transitions the signaling client state machine to a terminal state even if the call fails. The proper handling on success and on an error is to free the signaling client.

Parameters

[in] SIGNALING_CLIENT_HANDLE Signaling client handle

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ signalingClientDisconnectSync()

PUBLIC_API STATUS signalingClientDisconnectSync ( SIGNALING_CLIENT_HANDLE signalingClientHandle )

Disconnects the signaling client.

Parameters

[in] SIGNALING_CLIENT_HANDLE Signaling client handle

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ signalingClientFetchSync()

PUBLIC_API STATUS signalingClientFetchSync ( SIGNALING_CLIENT_HANDLE signalingClientHandle )

Fetches all assets needed to ready the state machine before attempting to connect. Can also be used to reallocate missing / expired assets before reconnecting.

Parameters

[in] SIGNALING_CLIENT_HANDLE Signaling client handle

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ signalingClientGetCurrentState()

PUBLIC_API STATUS signalingClientGetCurrentState	(	SIGNALING_CLIENT_HANDLE	signalingClientHandle,
		PSIGNALING_CLIENT_STATE	pState
	)

Gets the Signaling client current state.

Parameters

[in]	SIGNALING_CLIENT_HANDLE	Signaling client handle
[out]	PSIGNALING_CLIENT_STATE	Current state of the signaling client as an UINT32 enum

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ signalingClientGetIceConfigInfo()

PUBLIC_API STATUS signalingClientGetIceConfigInfo	(	SIGNALING_CLIENT_HANDLE	signalingClientHandle,
		UINT32	index,
		PIceConfigInfo *	ppIceConfigInfo
	)

Gets the ICE configuration information object given its index.

NOTE: The call will fail if the client is not in the CONNECTED state. IMPORTANT: The returned pointer to the ICE configuration information object points to internal structures and its contents should not be modified.

Parameters

[in]	SIGNALING_CLIENT_HANDLE	Signaling client handle
[in]	UINT32	Index of the ICE configuration information object to retrieve
[out]	PIceConfigInfo	The pointer to the ICE configuration information object

Returns: STATUS code of execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ signalingClientGetIceConfigInfoCount()

PUBLIC_API STATUS signalingClientGetIceConfigInfoCount	(	SIGNALING_CLIENT_HANDLE	signalingClientHandle,
		PUINT32	pIceConfigCount
	)

Gets the retrieved ICE configuration information object count.

NOTE: The call will fail if the client is not in the CONNECTED state.

Parameters

[in]	SIGNALING_CLIENT_HANDLE	Signaling client handle
[out]	PUINT32	The count of the ICE configuration information objects

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ signalingClientGetMetrics()

PUBLIC_API STATUS signalingClientGetMetrics	(	SIGNALING_CLIENT_HANDLE	signalingClientHandle,
		PSignalingClientMetrics	pSignalingClientMetrics
	)

Get signaling related metrics.

Parameters

[in]	SIGNALING_CLIENT_HANDLE	Signaling client handle
[in,out]	PSignalingClientMetrics	Signaling stats

Here is the call graph for this function:

◆ signalingClientGetStateString()

PUBLIC_API STATUS signalingClientGetStateString	(	SIGNALING_CLIENT_STATE	state,
		PCHAR *	ppStateStr
	)

Gets a literal string representing a Signaling client state.

Parameters

[in]	SIGNALING_CLIENT_HANDLE	Signaling client handle
[out]	PCHAR*	Read only string representing the state

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ signalingClientSendMessageSync()

PUBLIC_API STATUS signalingClientSendMessageSync	(	SIGNALING_CLIENT_HANDLE	signalingClientHandle,
		PSignalingMessage	pSignalingMessage
	)

Send a message through a Signaling client.

NOTE: The call will fail if the client is not in the CONNECTED state. NOTE: This is a synchronous call. It will block and wait for sending the data and await for the ACK from the service.

Parameters

[in]	SIGNALING_CLIENT_HANDLE	Signaling client handle
[in]	PSignalingMessage	Message to send.

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:

◆ transceiverOnBandwidthEstimation()

PUBLIC_API STATUS transceiverOnBandwidthEstimation	(	PRtcRtpTransceiver	pRtcRtpTransceiver,
		UINT64	customData,
		RtcOnBandwidthEstimation	rtcOnBandwidthEstimation
	)

Set a callback for bandwidth estimation results.

Parameters

[in]	PRtcRtpTransceiver	Populated RtcRtpTransceiver struct
[in]	UINT64	User customData that will be passed along when RtcOnBandwidthEstimation is called
[in]	RtcOnBandwidthEstimation	User RtcOnBandwidthEstimation callback

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ transceiverOnFrame()

PUBLIC_API STATUS transceiverOnFrame	(	PRtcRtpTransceiver	pRtcRtpTransceiver,
		UINT64	customData,
		RtcOnFrame	rtcOnFrame
	)

Set a callback for transceiver frame.

Parameters

[in]	PRtcRtpTransceiver	Populated RtcRtpTransceiver struct
[in]	UINT64	User customData that will be passed along when RtcOnFrame is called
[in]	RtcOnFrame	User RtcOnFrame callback

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ transceiverOnPictureLoss()

PUBLIC_API STATUS transceiverOnPictureLoss	(	PRtcRtpTransceiver	pRtcRtpTransceiver,
		UINT64	customData,
		RtcOnPictureLoss	onPictureLoss
	)

Set a callback for picture loss packet (PLI)

Parameters

[in]	PRtcRtpTransceiver	Populated RtcRtpTransceiver struct
[in]	UINT64	User customData that will be passed along when RtcOnPictureLoss is called
[in]	RtcOnPictureLoss	User RtcOnPictureLoss callback

Returns: STATUS code of the execution. STATUS_SUCCESS on success

◆ updateEncoderStats()

PUBLIC_API STATUS updateEncoderStats	(	PRtcRtpTransceiver	pRtcRtpTransceiver,
		PRtcEncoderStats	encoderStats
	)

call this function to update stats which depend on external encoder

Parameters

[in]	PRtcRtpTransceiver	transceiver for which encoder stats will be updated
[in]	PRtcEncoderStats	populated in the application layer which is then consumed as part of outgoingRtpStats

◆ writeFrame()

PUBLIC_API STATUS writeFrame	(	PRtcRtpTransceiver	pRtcRtpTransceiver,
		PFrame	pFrame
	)

Packetizes and sends media via the configuration specified by the RtcRtpTransceiver.

Parameters

[in]	PRtcRtpTransceiver	Configured and connected RtcRtpTransceiver to send media
[in]	PFrame	Frame of media that will be sent

Returns: STATUS code of the execution. STATUS_SUCCESS on success

Here is the call graph for this function:
